Huanyang VFD,110V 1-Phase to 220V 3-Phase,Variable Frequency Drive,for 220v 3phase 50/60hz Motor Speed Control (110V Input/220v Output-3hp)

NOTE：the item is not fit for capacitance motor(single phase motor) ,motor loads are not allowed to be too heavy specification：Input Voltage : 110v AC single phase Input Frequency: 47-63Hz Output Voltage : 220V AC three phase Output Frequency: 0-50Hz / 0-60Hz Suitable 220V 3phase Motor: ≤2.2KW Feature： ●RS485 communication port, adopting standard international MODBUS main circuit control●CWith extremely strong anti-jamming capability ●Low output ratting torque0.5HZ-150%, low speed running ability ●Carrier adjustable by 16KHZ, completely soundless working environment ●Broad voltage working area, normal running in 304V-456V ●Auto voltage regulation (AVR) technique, for ensuring the inverter load capability ●Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes●With perfect error protection and short circuit starting protection capability ●PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability ●Easy PLC function can realize 16 legs of speed and inverter control function

• The VFD can run 3-phase 220v motor with 110v AC single-phase input
• Supports mcah3 function and RS-485 communication
• Supports remote potentiometer speed control and remote switch start/stop
• Easy to connect the motor/easy to use
• Low failure rate/Designed to be non-flammable
• The VFD has the advantages of low noise and low electromagnetic interference
• Achieved CE listed
• 1 Year replace .If there is an error code in the vfd and you do not know how to operate, pls contact me or the after-sales service
