Huanyu Cross Sliding Vise Metal Bench Clamp Drill Press Vice Engineering Working Milling Maschine Industrial Heavy-duty Benchtop (8 Inch)

Huanyu Huanyu Instrument mainly provides instruments and tools. Specifications: Model: QM16 Material: cast iron Length:13.98inch Height:7.56inch Width of jaw:7.87inch Maximum clamping:7.87inch Jaw height:2.1inch length of base:12.6inch Cross range:7.8*7.5inch Weight:36kg Reminder: Some of the workpieces might be slightly damaged due to their material or too much force applied. As such, in order to protect your workpieces from being damaged, materials that are softer than your workpiece could be stacked between workpiece and vice jaws such as paper or soft metal for protection)

• 【Two vertical feed structures】: It can move in both left and right directions and drill multiple holes in the same plane in one clamp.
• 【Precision type】: The parallelism and verticality of the tongs are less than 0.025 mm/100 mm.
• 【Special design of clamp】：Deep grinding technology is used on the face A of the clamp, B surface is die-cast with cross-deep V-groove carbon grain, Which makes it smooth and precise.
• 【Accurate fine-tuning knob adjustment】: The dial is clear and unambiguous.
• 【Equipped with track tightening adjusting screw】: When the track is too tight or too loose at work, the hexagonal wrench is used to adjust to the desired degree, and the mother fixed outside is tightened. The adjustment is convenient, time-saving, labor-saving and more worry-saving.
