NetXtreme 10/100/1000 PCIe x1 Single Gigabit Fiber Port 1Gb Ethernet PCI Express Network Cards Adapter with Broadcom BCM5720 Chipset

DescriptionThe PCIe BCM5720 NetXtreme Gigabit Fiber network card is a thirteenth-generation 10/100/1000BAST-T Ethernet LAN controller solution suitable for high-performance server applications.it built on proven architecture and provides a PCI Express v2.0 compliant host interface, which can operate at 5Gb/s or 2.5Gb/s at x1 link width. The adapter card supports offload technologies including large Send, TCP segmentation, And TCP/UDP/IP checksum, and receive-side scaling that deliver optimal network throughput, lower host processor utilization and as a result improve system overall performance. the adapter card comes in small form factor that is suitable for both low-profile and standard chassis.Specification Integrated 1000MBASE-X/SGMII 1.25Gbaud SerDes transceivers Energy Efficient Ethernet (EEE) compliant with IEEE Std 802.3az-2010 X1 PCI Express v2.0 at 5GT/s or 2.5GT/s I/O Virtualization (IOV) Support for VMWare○R NetQueue and Microsoft○R VMQ 17 receive queues and 16 transmit queues TLP Processing Hint (TPH) ECN to the PCI Express Base Specification v2.0 Receive Side Scaling (RSS) with per queue MSI-X vector support and support for UDP RSS hash type Jumbo frame support for up to 9600-byte payload Virtual LAN(VLAN) support-IEEE802.1q VLAN tagging TCP, IP, UDP checksum offload Large send offload (LSO), TCP segmentation offload (TSO) Hardware assist for IEEE1588 and IEEE802.1AS time synchronization implementation IEEE802.3x flow control SMBus 2.0 interface Statistics for SNMP MIB II, Ethernet-like MIB and Ethernet MIB (IEEE802.3z Clause30) Advanced power management by a central power management unit (CPMU) Power Management offload Drivers for NT/2000/XP/Win7 / Win8 / Win10 / Vista / Sever2008 / Sever 2012 / Linux2.2 and abovePackage content 1 x PCIe BCM5720 NetXtreme Gigabit Fiber Network card 1 x User’s Manual 1 x CD 1 x Low profile bracket System Requirements Linux, NT/2000/XP/Win7/ Win-server2012/ Win-server2008/ Win8/Win8.1/Win-server2016/win10One available PCI Express x1/x4/x8/x16 slot

• The PCIe BCM5720 NetXtreme Gigabit Fiber network card is a thirteenth-generation 10/100/1000BAST-T Ethernet LAN controller solution suitable for high-performance server applications.
• It built on proven architecture and provides a PCI Express v2.0 compliant host interface, which can operate at 5Gb/s or 2.5Gb/s at x1 link width.
• The adapter card supports offload technologies including large Send, TCP segmentation, And TCP/UDP/IP checksum, and receive-side scaling that deliver optimal network throughput, lower host processor utilization and as a result improve system overall performance.
• The adapter card comes in small form factor that is suitable for both low-profile and standard chassis.
• Drivers for NT/2000/XP/Win7 / Win8 / Win10 / Vista / Sever2008 / Sever 2012 / Linux2.2 and above
